RLA-PoECS1 offers a cost-effective solution by enabling the operation of two cameras using a single Ethernet cable. In this article, we will provide a detailed introduction to the RLA-PoECS1.
Applies to: Reolink PoE cameras (exclude RLC-823A, RLC-823A 16x, RLC-823S1, RLC-823S2) and NVRs (only hardware version N5MB01/N6MB01/N7MB01 is supported)
Whether you're looking to expand your existing surveillance system or have purchased multiple cameras simultaneously and want to avoid the hassle of additional wiring, RLA-PoECS1 is here to help.
RLA-PoECS1 consists of a combiner, a splitter, and three waterproof lids. Here's how each component functions:
- Combiner: Equipped with two RJ45 male connectors, the combiner can combine the data and PoE power from two ports into one cable. Both RJ45 connectors should be plugged into a PoE switch or a Reolink NVR.
- Splitter: The splitter features two RJ45 female connectors, facilitating the transfer of data and PoE power to two cameras.
- Waterproof Lids: The three waterproof lids are included to protect the connectors at the splitter end.
Note: The combiner and splitter must be used together. It is essential to avoid using only one of these two units to connect the cameras.
The connection diagram is shown in the picture below:
