This guide will walk you through the installation process for the outdoor security mount of your Reolink Argus PT Ultra and Go PT Ultra cameras.
There are three methods of installation available:
Mount the camera to the wall
1. Use the mounting hole template to drill holes in the wall. Then, screw the camera bracket securely into place.
Note: Use the drywall anchors included in the package if needed.
2. Attach the antenna to the camera.
3. Align the white hole on the top of the camera with the white hollow screw on the bracket. Use the wrench and hex head screw provided to firmly secure the camera in place. Finally, cover the rubber plug.
Mount the camera to the ceiling
1. Drill holes in the ceiling. Then, screw the camera bracket securely into place.
2. Attach the antenna to the camera.
3. Align the camera with the mount base and turn the camera unit clockwise to lock it in position.
Install the Camera with Loop Strap
If desired, you can strap the camera to a tree with both the security mount and the ceiling bracket. Follow these steps:
Thread the provided strap to the bracket or the mount base and fasten it securely around a tree.
Congratulations! You have successfully installed your Argus PT Ultra/Go PT Ultra camera.
